3.95/3.30 mm, 4 Pins, Non Standard Connectors, 3.15/2.30 mm Working Height, Pitch 2.4 mm

3.95/3.30 mm, 4 Pins, Non Standard Connectors, 3.15/2.30 mm Working Height, Pitch 2.4 mm
Previous Pause Next
  • 0
  • 1
Category
Non Standard Connectors
Part Number P2653MF02-04A240HR
Pin Direction Vertical
Pin Tail Soldering Cup
Pin Amount 4
Pitch 2.40
Rated Current 1.5/1
Contact Resistance 50 mΩ
Datasheet P2653MF02-04A240HR-Model.pdf
3D CAD P2653MF02-04A240HR.STEP
Get a Quotation
Lead Time 28

Product Specifications

Plunger Base Brass
Plunger Plating CuSnZn/Au
Barrel Base Brass
Barrel Plating CuSnZn/Au
Spring Base 85/70
Housing Sabic PC+20%GF
Rated Current 1.5/1 A
Rated Voltage 12 V
Contact Resistance 50 mΩ
Spring Force 85/70 g ± 20%
Life Cycle 10000

Description

P2653MF02-04A240HR
